Modular optical CATV node
€ 375.00
Modular optical CATV node for DOCSIS 3.1 specification
Specification
| Order number | 00212107 |
|---|---|
| EAN-Code | 4026187197797 |
OFN210-FR-1310-65 AC
18 in stock
Product Details
- Fibre node for DOCSIS 3.1 specification
- Automatic Gain Control (AGC)
- High RF output level usable for MDU or larger coax network
- Return Path with OBI free burst or continuous mode
- Standard 1310 nm DFB laser in return (CWDM DFB laser optionally)
- Flexible DS/US band with plug-in diplexer: 65/87 or 204/258 (set higher US bandwidth can be done at later)
- Equalizer and ATT electronically adjustable
- Frequency range forward 1218 MHz
- Separate DS and US Fibre connection 2 x SC/APC
Download Details
-
Anleitung OFN210 DE pdf · 2mb
-
MAnual OFN210 EN pdf · 2mb
-
Datenblatt OFN210 DE pdf · 2mb
-
Data sheet OFN210 EN pdf · 2mb
-
Blockschaltbild OFN210 pdf · 2mb
